5-Axis Type Double-Column Machining Center
KMC-RF

5-Axis Type Double-Column Machining Center

Features:

  • All 3 axes travels are fully supported by boxway hereby ensuring the rigidity and stability.

  • 3 axes have larger travel range;extraordinarily Z-axis stroke is 1100mm.

  • All surfaces that make contact with the slideways are lined with Turcite-B to ensure long lasting and optimum rigidity during heavy cutting conditions.

  • The mounting brackets for the Y and Z axis ballscrews are integrated with the saddle and crossbeam casting to maximize the rigidity further.

  • Mechanical safety couplings are used where the drive motors adapt to the ballscrews. These devices greatly minimize damage that may occur during a collision or overload condition.

  • A ram-type casted spindle head with a cross section of 400x400mm ensures high rigidity and stability under heavy-duty cutting.

  • Standard 2-station AAC including angular head and vertical head is designed for improving productivity; 30°angle head, extension head and universal head are optionally available for versatile applications.

High Rigidity Double-Column Machining Center


※: Option design and specifications are subject to change without notice.
